The simple, low-cost fabrication technique - developed by researchers at the Georgia Institute of Technology, Wisconsin-Madison University and Superior Graphite - was designed to be easily scaled up and compatible with existing battery manufacturing.
‘The development of a novel approach to producing hierarchical anode or cathode particles with controlled properties opens the door to many new directions for lithium-ion battery technology,’ said Gleb Yushin, an assistant professor in the School of Materials Science and Engineering at the Georgia Institute of Technology. ‘This is a significant step towards the commercial production of silicon-based anode materials for lithium-ion batteries.’
Lithium-ion batteries transfer lithium ions between the cathode and an anode via a liquid electrolyte. The more efficiently the lithium ions can enter the two electrodes during charge and discharge cycles, the larger the battery’s capacity will be.
Existing lithium-ion batteries are said to rely on anodes made from graphite. Silicon-based anodes theoretically offer as much as a 10-fold capacity improvement over graphite, but silicon-based anodes have so far not been stable enough for practical use.
Graphite anodes use particles ranging in size from 15 to 20 microns. If silicon particles of that size are substituted for the graphite, expansion and contraction as the lithium ions enter and leave the silicon create cracks that cause the anode to fail.
The new nanocomposite material reportedly solves that degradation problem, potentially allowing battery designers to tap the capacity advantages of silicon. That could facilitate higher power output from a given battery size or allow a smaller battery to produce a required amount of power.
‘At the nanoscale, we can tune materials’ properties with much better precision than we can at traditional size scales,’ said Yushin. ‘This is an example of where having nanoscale fabrication techniques leads to better materials.’
Electrical measurements of the new composite anodes in small coin cells showed they had a capacity more than five times greater than the theoretical capacity of graphite.
Fabrication
Fabrication of the composite anode begins with the formation of highly conductive branching structures – similar to the branches of a tree – made from carbon black nanoparticles annealed in a high-temperature tube furnace. Silicon nanospheres with diameters of less than 30nm are then formed within the carbon structures using a chemical vapour deposition process.
Using graphitic carbon as an electrically conductive binder, the silicon-carbon composites are then self assembled into rigid spheres that have open, interconnected internal pore channels. The spheres, formed in sizes ranging from 10 to 30 microns, are used to form battery anodes. The relatively large composite powder size – 1,000 times larger than individual silicon nanoparticles – enables easy powder processing for anode fabrication.
The internal channels in the silicon-carbon spheres serve two purposes: they admit liquid electrolyte to allow the rapid entry of lithium ions for quick battery charging and they provide space to accommodate the expansion and contraction of the silicon without cracking the anode. The internal channels and nanometre-scale particles also provide short lithium diffusion paths into the anode, boosting battery-power characteristics.
The size of the silicon particles is controlled by the duration of the chemical vapour deposition process and the pressure applied to the deposition system. The size of the carbon nanostructure branches and the size of the silicon spheres determine the pore size in the composite.
The production of the silicon-carbon composites could be scaled up as a continuous process amenable to ultra-high-volume powder manufacturing, according to Yushin. As the final composite spheres are relatively large when they are fabricated into anodes, the self-assembly technique avoids the potential health risks of handling nanoscale powders, he added.
Once fabricated, the nanocomposite anodes would be used in batteries just like conventional graphite structures. That would allow battery manufacturers to adopt the new anode material without making significant changes in production processes.
So far, the researchers have tested the new anode through more than 100 charge-discharge cycles. Yushin believes that the material would remain stable for thousands of cycles because no degradation mechanisms have become apparent.
‘If this technology can offer a lower cost on a capacity basis, or lighter weight compared to current techniques, this will help advance the market for lithium batteries,’ he said. ‘If we are able to produce less expensive batteries that last for a long time, this could also facilitate the adoption of many “green” technologies, such as electric vehicles or solar cells.’
