Photon-friendly graphene membranes mimic photosynthesis to produce hydrogen

Graphene membranes that mimic photosynthesis to produce hydrogen by harvesting solar energy could be developed following the discovery of a new effect.

Graphene membrane

Researchers at Manchester University have discovered that the rate at which graphene conducts protons increases 10 fold when it is illuminated with sunlight.

Dubbed the “photo-proton” effect, the finding could lead to graphene membranes being used to produce hydrogen from artificial photosynthesis, as well as for light-induced water splitting, photo-catalysis and in photodetectors.

Graphene – a one atom-thick sheet of carbon – is already known to be an extremely good conductor of electrons, and can absorb light of all wavelengths.

But it has also recently been found to be permeable to thermal protons, the nuclei of hydrogen atoms.

To discover how light affects the behaviour of these protons, the researchers fabricated graphene membranes and decorated them on one side with platinum nanoparticles.

When they illuminated the membrane with sunlight, they found the proton conductivity increased by 10 times, according to Dr Marcelo Lozada-Hidalgo, who led the research alongside Prof Sir Andre Geim.

“This is a new effect, it can only be found in graphene, there are no other materials that can use light to produce an enhancement in proton transport,” said Lozada-Hidalgo. “Scientifically this is a new physical phenomenon, which is quite remarkable.”

New catalyst material could ignite fuel cell revolution

What’s more, when the researchers measured the photoresponsivity of the membrane using electrical measurements and mass spectrometry, they discovered that around 5,000 hydrogen molecules were being formed in response to every light particle. Existing photovoltaic devices need thousands of photons to produce a single hydrogen molecule.

“To put this in context, people have been developing silicon photodiodes for the best part of 50 years, while we did not expect this material to be responsive to light in the first place, and found that it outperforms pretty much everything that is out there,” said Lozada-Hidalgo.

The researchers have published their findings in Nature Nanotechnology. They now plan to investigate the addition of catalysts to the membrane, to enable it to split water molecules. This would allow it to act as a complete artificial leaf, said Lozada-Hidalgo.

“The goal of this project is to make an artificial leaf, to split water molecules and then use the protons to generate hydrogen,” he said. “What we’re missing is the bit to break the water in the first place, and for that we need another catalyst.”
