Airborne ice warning

Beginning today, air traffic controllers and pilots in the US will receive detailed updates on in-flight icing, which can endanger commuter planes and larger commercial aircraft.

Graphical displays, developed by researchers at the US National Center for Atmospheric Research (NCAR), will for the first time rate areas by icing severity and the probability of encountering icing conditions. The enhanced in-flight icing product is intended to increase safety and reduce flight delays by guiding aircraft away from potentially hazardous icing conditions, thus saving the aviation industry more than $20m per year in injuries, aircraft damage, and fuel.

The displays are part of an upgrade to a system called CIP (Current Icing Product). They will be available to air traffic controllers, pilots, and other aviation weather users. The product has been developed at NCAR with funding from the Federal Aviation Administration (FAA).

'This is a major advance that will enable dispatchers and even pilots to choose flight paths that avoid icing conditions,' said Marcia Politovich, who oversees in-flight icing research at NCAR. 'This product will help make commuter flights safer, and it will also enable commercial airlines to avoid the delays and excessive fuel costs associated with in-flight icing.'

Icy weather, including ice pellets and cloud droplets that freeze on contact, may affect air travel anywhere in the US, especially during colder months. When ice builds up on aircraft wings, it can increase the drag on the airplane and make staying aloft more difficult. Even when aircraft are certified to fly through icing conditions, the risk can prompt pilots to detour for hundreds of miles.

Upgrading a proven product

In 2002, the FAA approved the first version of the CIP as a tool for dispatchers to make fly/no-fly decisions, plan flights, change routes, and select altitudes. The high-precision maps and plots displayed online were derived from surface observations, numerical models, satellite and radar data, and pilot reports.

The new version of CIP, which is updated hourly with selectable altitudes up to 29,000 feet, is said to incorporate more advanced weather prediction models and more detailed observations. Instead of simply indicating the potential for icing, it quantifies the probability of icing encounters and their likely severity. Pilots of properly equipped aircraft will be able to fly through areas of light icing instead of detouring around wide regions with potential icing conditions.

A major advance over the previous version of the CIP is that pilots will be able to access the maps in the cockpit, helping them to make course adjustments as needed.

The new version of CIP will most benefit commuter planes and other smaller aircraft, said Politovich. Such aircraft are more vulnerable to icing hazards because they cruise at lower, ice-prone altitudes, below 18,000 feet. They also lack mechanisms common on larger jets that prevent ice build-up by heating the front edges of wings. Using the CIP displays, controllers will be able to guide incoming commercial jets so they avoid circling at altitudes where ice could accumulate.
