Gas unmasked

A powerful greenhouse gas is at least four times more prevalent in the atmosphere than previously estimated, according to a team of researchers at Scripps Institution of Oceanography at UC San Diego.

Using new analytical techniques, a team led by Scripps geochemistry Prof Ray Weiss made the first atmospheric measurements of nitrogen trifluoride (NF3), which is thousands of times more effective at warming the atmosphere than an equal mass of carbon dioxide.

The amount of the gas in the atmosphere, which could not be detected using previous techniques, had been estimated at less than 1,200 metric tons in 2006. The new research shows the actual amount was 4,200 metric tons. In 2008, about 5,400 metric tons of the gas was in the atmosphere, a quantity that is increasing at about 11 per cent per year.

‘Accurately measuring small amounts of NF3 in air has proven to be a very difficult experimental problem and we are very pleased to have succeeded in this effort,’ Prof Weiss said.

Emissions of NF3 were thought to be so low that the gas was not considered to be a significant potential contributor to global warming. It was not covered by the Kyoto Protocol, the 1997 agreement to reduce greenhouse gas emissions signed by 182 countries.

The gas is 17,000 times more potent as a global warming agent than a similar mass of carbon dioxide. It survives in the atmosphere about five times longer than carbon dioxide. Current NF3 emissions, however, contribute only about 0.15 per cent of the total global warming effect contributed by current human-produced carbon-dioxide emissions.

Nitrogen trifluoride is one of several gases used during the manufacture of liquid crystal flat-panel displays, thin-film photovoltaic cells and microcircuits. Many industries have used the gas in recent years as an alternative to perfluorocarbons, which are also potent greenhouse gases, because it was believed that no more than two per cent of the NF3 used in these processes escaped into the atmosphere.

The Scripps team analysed air samples gathered over the past 30 years, working under the auspices of the NASA-funded Advanced Global Atmospheric Gases Experiment (AGAGE) network of ground-based stations.

The network was created in the 1970s in response to international concerns about chemicals depleting the ozone layer. It is supported by NASA as part of its congressional mandate to monitor ozone-depleting trace gases, many of which are also greenhouse gases.

Air samples are collected at several stations around the world. The Scripps team analysed samples from coastal clean-air stations in California and Tasmania for their research.

The researchers found concentrations of the gas rose from about 0.02 parts per trillion in 1978 to 0.454 parts per trillion in 2008. The samples also showed significantly higher concentrations of NF3 in the Northern Hemisphere than in the Southern Hemisphere, which the researchers said is consistent with its use predominantly in Northern Hemisphere countries.

In response to the growing use of the gas and concerns that its emissions are not well known, scientists have recently recommended adding it to the list of greenhouse gases regulated by Kyoto.
