IBM demonstrates world's fastest optical chipset

At the 2007 Optical Fiber Conference, IBM scientists will reveal a prototype optical transceiver chipset capable of reaching speeds at least eight times faster than optical components available today.

The breakthrough could transform how data is accessed, shared and used across the internet for corporate and consumer networks. According to IBM, the transceiver is fast enough to reduce the download time for a typical high definition feature-length film to a single second compared to around 30 minutes over the best available systems today.

The ability to move information at speeds of 160 Gigabits -- or 160 billion bits of information in a single second -- provides a glimpse of a new era of high-speed connectivity that IBM claims will transform communications, computing and entertainment. Optical networking offers the potential to dramatically improve data transfer rates by speeding the flow of data using light pulses, instead of sending electrons over wires.

‘The explosion in the amount of data being transferred, when downloading movies, TV shows, music or photos, is creating demand for greater bandwidth and higher speeds in connectivity,’ said Dr. T.C. Chen, vice president, Science & Technology, IBM Research. ‘Greater use of optical communications is needed to address this issue. We believe our optical transceiver technology may provide the answer.’

As the amount of data transmitted over networks continues to grow, researchers have been looking for ways to make the use of optical signals more practical. The ability to use these signals could offer previously unheard of amounts of bandwidth and enhanced signal fidelity compared to current electrical data links. By shrinking and integrating the components into one package, and building them with standard low-cost, high-volume chip manufacturing techniques, IBM claims it is making optical connectivity viable for widespread use.

The technology could be integrated onto printed circuit boards to allow the components within an electronic system -- such as a PC or set top box -- to communicate much faster, enhancing the performance of the system itself.

To achieve this new level of integration in the chipset, IBM researchers built an optical transceiver with driver and receiver integrated circuits in current CMOS technology, the same standard, high-volume, low-cost technology used for most chips. They then coupled it with other optical components made with materials such as indium phosphide (InP) and gallium arsenide (GaAs) into an integrated package measuring 3.25mm x 5.25mm.

This compact design provides a high number of communications channels as well as very high speeds per channel, resulting in an amount of information transmitted per unit area of card space taken up by the chipset (the ultimate measure of viability for practical use) that is the highest ever. This transceiver chipset is designed to enable low cost optics by attaching to an optical printed circuit board employing densely spaced polymer waveguide channels using mass assembly processes.
