Multi-industry application

1 min read

The new Quad Series from Clare Instruments is the first tester that can be used to HiPOT/flash test electrical products with in-built internal circuitry while they are connected to an isolated power supply.

The new Quad Series from Clare Instruments is the first tester that can be used to  HiPOT/flash test electrical products with in-built internal circuitry  while they are connected to an isolated power supply.

Typical  products  that incorporate internal circuits are  microprocessor  based domestic/industrial  washing machines, cooking appliances, consumer  audio/TV/IT products  and  construction machinery built to international standards  such  as IEC355, IEC950, IEC601, IEC598, and IEC204.

The  Quad  is  available  in  both  single and  three  phase  options  for  user flexibility and ease-of-operation.

Test  results are displayed on the HAL Flash and Insulation Tester  via  a  high contrast  large LCD backlit display, with intuitive rotary encoder and soft  key controls to enable system configuration.

The HAL has been specifically designed to meet HiPot flash testing and test data traceability  demands  associated  with  modern  quality  assurance  and  safety standards. Operation of the new instrument complies with the recently introduced EN 50191 electrical safety testing standard.

The  unit  is  capable  of  carrying out AC or DC flash testing  and  insulation testing  in both open and closed area test environments. User-friendly  controls and  programmable options for establishing test voltages, ramping times, leakage limits  and other parameters allow complex test sequences to be generated safely and effectively.

Clare  Instruments, part of the Seaward Group, is a market leading  supplier  of electrical safety testing instrumentation and systems for manufacturers  serving international  markets.
