Sparky system

1 min read

Nissan Motor has developed what its says is the world's first technology to measure in-cylinder gas temperatures.

Working with

Stanford University


Physical Science

(PSI), Japanese auto giant

Nissan Motor

has developed what it says is the world's first technology to measure in-cylinder gas temperatures and a way to analyse the combustion in ‘real-time’ during engine operation.

The temperature measurement system uses the established technology of Tunable Diode Laser Absorption Spectroscopy (TDLAS).

To measure temperature, a laser beam, carried by optical fibres through a probe having the form of a spark plug, is transmitted across a short segment of the cylinder of an engine. The laser beam is then partially absorbed by gases in the cylinder at two discrete wavelengths. And by determining the ratio of absorbance of the laser at the two wavelengths, the gas temperature can be calculated.

Nissan's specific role was in the optical design of temperature probe and overall project management, while Stanford University researchers were in charge of creating the basic concepts and methodology. PSI took charge of laser device development.

Previous methods to measure the temperature required modifications to the engine. But it was difficult to acquire useful data from methods such as attaching sensors inside the cylinder wall or estimating the temperature from camera images of the flame obtained in a specially modified optical-access engine.

Detailed results from the system will be published by the Institute of Physics and by the Optical Society of America in 2006, and also by the Society of Automotive Engineers International.
