UK trials are scheduled for bespoke 3D printed medical-grade titanium-alloy implants that could bring relief to knee osteoarthritis sufferers.

TOKA
The bespoke implant preserves the existing joint and can be used at an earlier stage of arthritis, before a knee replacement is needed (Image: Bath University)

Developed by engineers at Bath University’s Centre for Therapeutic Innovation (CTI), the TOKA (Tailored Osteotomy for Knee Alignment) treatment improves the operative procedure and fit of high-tibial osteotomy (HTO) plates used to realign a patient's knee, making them more stable, comfortable and better able to bear weight than existing generic plates. The technique is also said to simplify HTO surgery, making operations quicker and safer.

The HTO plates have been tested virtually in a computer-based trial using CT scan data from 28 patients. The in-silico clinical trial, the first in the world to demonstrate the safety of an orthopaedic device, modelled the stresses that would be exerted on the bespoke plates and showed that they would be comparable in safety to the standard treatment.

3D printed implant could help therapy for spinal cord injuries

In a statement, Professor Richie Gill, from the Centre for Therapeutic Innovation, said: "Knee osteoarthritis is a major health, social and economic issue and does not receive as much attention as it should. A quarter of women over 45 have it, and about 15 per cent of men, so it's a significant burden that many live with.

"Knee replacement is only useful for end-stage osteoarthritis, so you can be in pain and have to live with a disability for a long time, potentially decades, before it's possible. We hope that the new TOKA process we've developed will change that."

Knee osteoarthritis patients undergoing TOKA will undergo a 3D CT scan of their knee, before a personalised 3D printed surgical guide and plate, both shaped to their tibia bone is created. The surgical guide simplifies the surgery and is designed to improve surgical accuracy.

The process also sees the first implementation of 3D printed screw threads into the HTO plates, which can be optimally positioned to help secure them against the bone.

Hospitals in Bath, Bristol, Exeter and Cardiff will take part in a randomised control trial to compare patient outcomes with an existing generic HTO procedure. Tests of the TOKA technique have already begun in Italy, where 25 patients received new personalised HTO plates as part of a trial at the Rizzoli Institute in Bologna.

HTO surgery realigns the knee joint by making a cut to the tibia and opening a small gap, which needs to be stabilised by a metal plate. This realignment moves the loading to a less 'worn' part of the knee and patient outcomes depend on how accurately the cut is made and the gap opened.

Prof Gill said: "The HTO surgery has a long clinical history and it has very good results if done accurately. The difficulty surgeons have is achieving high accuracy, which is why we have created the TOKA method, which starts with a CT scan and digital plan.

"3D printing the custom knee implant and doing the scanning before operating means surgeons will know exactly what they'll see before operating and where the implant will go."

The pre-planning element greatly simplifies surgery and could cut the time on the operating table from two hours to around 30 minutes.

The work to date and UK trial is supported and funded by Versus Arthritis. The in-silico trial has been published in Communications Medicine.
