Labview powers op amp selector

Analog Devices has launched a parametric evaluation tool for amplifiers that enables system designers to select, evaluate and troubleshoot voltage feedback operational amplifiers from the company.

By using parametric data to mathematically model the general behaviour of a selected amplifier, designers are able to select a component, quickly configure a circuit, apply a signal and evaluate the amplifier’s general performance.

The tool, available to users at no charge, is accessible on the Analog Devices Web site and requires no software download.

The parametric evaluation tool enables designers to check an amplifier’s parametric performance, such as bandwidth limitations, input/output range, gain errors, and DC errors in a given circuit configuration. By observing the limits specified by these parameters, the designer is ensured that the device is safely and reliably operating well within its optimal performance range.

The evaluation tool also offers several key features that aid in the selection of amplifiers from Analog Devices. For instance, once a circuit has been set, a designer can request a list of the amplifiers that would best fit a given design.
